Inspection Light Bars

A
$349.17 USD - $390.37 USD
Shipping calculated at checkout.
SKU: SP40ILB
Model: 40" Inspection Light Bar
$390.37 USD
$390.37 USD
Short Description

24” wide, 36 watt – 24 LEDs in double row stack allows operator more viewing ease for thicker parts. Suitable for smaller parts “manicure” stations

36” wide, 60 watt – 36 LEDs in single row suitable for easily identifying defects coming off a wide sanding line or parts larger than 2’ or multiple parts on one table

Inspection Light Bars are used across North America from the largest cabinet building OEM production shops to small refinisher businesses. This light helps you see any imperfection on the surface so you can deliver the best quality finished product to your customer.

LED Inspection Light Specifications

  • Each LED has a 30,000 to 50,000 hour life span.
  • LED light bar consumes 0-60 watts.
  • Shock and vibration resistant.
  • The technology gives off very low heat per lumen for operator comfort.
  • Warm 5,500 to 6,000K light temperature is closer to daylight, which is better for color rendition.
  • The perfectly smooth beam quality and low level illumination make defects 10X more visible.
  • The lenses help angle the light toward the sanding surface for inspection.
<p style="text-align: left;"><strong>POWER:</strong> SP24ILB = 36W | SP40ILB = 60W</p>
<p style="text-align: left;"><strong>VOLTAGE:</strong>  110V - US Plug Included</p>
<p style="text-align: left;"><strong>DIMENSIONS 24”(SP24ILB):</strong>
Measurements with visor and feet:
81/4” deep X 3” high X 24” long with 24 lights</p>
<p style="text-align: left;"><strong>DIMENSIONS 40” (SP40ILB):</strong>
Measurements with visor and feet:
81/4” deep X 3” high X 391/8” long with 36 lights</p>
<p style="text-align: left;"><strong>BODY COLOR:</strong> Red</p>
<p style="text-align: left;"><strong>LUMENS:</strong> SP24ILB = 3000-3300lm; SP40ILB = 4800-5100lm</p>
<p style="text-align: left;"><strong>COLOR TEMPERATURE:</strong>  Cool White 6000K</p>
<p style="text-align: left;"><strong>LED QUANTITY:</strong></p>
<p style="text-align: left;">SP24ILB = 24pcs 2W LEDs (output 36W)
SP40ILB = 36pcs 2W LEDs (output 60W)
<strong>PF</strong> &gt;0.95</p>
<p style="text-align: left;"><strong>EFFICIENCY:</strong> 89%
LENS BEAM ANGLE: 45degrees / clear lens</p>
<p style="text-align: left;"><strong>MOUNTING:</strong> Two Brackets, Accept customization</p>
<p style="text-align: left;"><strong>IP RATING:</strong> IP65</p>
<p style="text-align: left;"><strong>LIFE SPAN:</strong> &gt;50,000 hours</p>
<p style="text-align: left;"><strong>WARRANTY:</strong> 2 Years</p>
<p style="text-align: left;"><strong>DIMMER:</strong> No dimmer, accept customization (DALI, DMX,
0-10V)</p>
Download

LED Light Informational Flyer

Download

2 Year Manufacturer's Warranty
